R100

The R100 is an advanced Phased Array UAS Detection Radar designed for high-precision monitoring of Low, Slow, and Small (LSS) targets. Moving away from traditional mechanical turntable structures, it utilizes a software-defined architecture to provide adaptive environmental perception.

 Functions & Features

• Phased Array Technology: Available in single-sided or four-sided configurations, it uses distributed digital antennas and joint optimization of transmit/receive beams for 360° azimuth coverage.

• Massive Tracking Capacity: It can concurrently track ≥100 items within an operating band of 9GHz to 12GHz, maintaining situational awareness in high-density environments.

• Precision Performance: The system offers a range accuracy of ≤5m and an angle accuracy of ≤0.5°, supporting tracking speeds from 1m/s to 150m/s.

 Advantages

• Superior Clutter Suppression: Advanced beamforming and PAPR constraints increase the clutter suppression ratio by 30dB, solving the problem of ground interference at low elevation angles.

• Long-Range Surveillance: It features a detection distance of ≥12km and an altitude reach of ≥2km, providing a massive protective dome.

• Rugged & Scalable: With an IP66 rating and modular array surfaces, it is built for diverse applications, from critical infrastructure to border security.
